A Study of PGM-Free Oxidation Catalyst YMnO3 for Diesel Exhaust Aftertreatment

2012-06-18
Manganese oxides show high catalytic activity for CO and HC oxidation without including platinum group metals (PGM). However, there are issues with both thermal stability and resistance to sulfur poisoning. We have studied perovskite-type YMnO3 (YMO) with the aim of simultaneously achieving both activity and durability. This paper describes the oxidation activity of PGM-free Ag/i-YMO, which is silver supported on improved-YMO (i-YMO). The Ag/i-YMO was obtained by the following two methods. First, Mn4+ ratio and specific surface area of YMO were increased by optimizing composition and preparation method. Second, the optimum amount of silver was supported on i-YMO. In model gas tests and engine bench tests, the Ag/i-YMO catalyst showed the same level of activity as that of the conventional Pt/?-Al2O3 (Pt = 3.0 g/L). In addition, there was no degradation with respect to either heat treatment (700°C, 90 h, air) or sulfur treatment (600°C to 200°C, total 60 h, 30 ppm SO2).
Technical Paper

Management System for Continuously Variable Valve Lift Gasoline Engine

2007-04-16
2007-01-1200
A continuously variable valve lift gasoline engine can improve fuel consumption by reducing pumping loss and increase maximum torque by optimizing valve lift and cam phase according to engine speed. In this research, a new control system to simultaneously ensure good driveability and low emissions was developed for this low fuel consumption, high power engine. New suction air management through a master-slave control made it possible to achieve low fuel consumption and good driveability. To regulate the idle speed, a new controller featuring a two-degree-of-freedom sliding-mode algorithm with cooperative control was designed. This controller can improve the stability of idle speed and achieve the idle operation with a lower engine speed. To reduce emissions during cold start condition, an ignition timing control was developed that combine I-P control with a sliding mode control algorithm.
Technical Paper

Establishment of the Specification Design Technique by Multiple-Purpose Optimization of Sound Proof Package

2007-04-16
2007-01-1544
This paper describes an effective method with statistical energy analysis (SEA) for specifying the vehicle sound proof package that achieves the best balance between light weight and high sound insulation performance. For proposing the sound proof package in the early stages of vehicle development, it is necessary to assess a number of specifications and to pick the best design specifications for weight and sound proof performance. However, there are difficulties in achieving conflicting objectives simultaneously, and acoustic engineers need special technical know-how. In this study, a new automated optimization method is proposed that approaches the problem above. As a result, detailed sound insulation package specifications, including the thickness distribution of each part, can be obtained and these can be easily transferred to drawings. Moreover, the accuracy of this method is proven by a reduction in vehicle interior cabin sound pressure level
Technical Paper

Liquid Phase Thermometry of Common Rail Diesel Sprays Impinging on a Heated Wall

2007-07-23
2007-01-1891
An experimental study was carried out on visualization of liquid phase temperature distributions in high-pressure diesel sprays impinging on a heated wall. Naphthalene/TMPD-exciplex fluorescence method and pyrene-excimer fluorescence method were utilized for the thermometry. The sprays were injected into a high-pressure and high-temperature gaseous environment. The nozzle hole diameter was 0.100 mm or 0.139 mm. The results showed that cool pockets were formed at the tip and in the impinging part of the sprays. The spray for the nozzle with 0.100 mm hole was heated up faster near the nozzle than for the nozzle with 0.139 mm hole.
Technical Paper

Study on Emission Reducing Method with New Lean NOX Catalyst for Diesel Engines

2007-07-23
2007-01-1933
In recent years, emission regulations have become more stringent as a result of increased environmental awareness in each region of the world. For diesel engines, reducing NOX emissions is a difficult technical challenge.[1],[2],[3],[4]. To respond to these strict regulations, an exhaust gas aftertreatment system was developed, featuring a lean NOX catalyst (LNC) that uses a new chemical reaction mechanism to reduce NOX. The feature of the new LNC is the way it reduces NOX through an NH3-selective catalytic reduction (SCR), in which NOX adsorbed in the lean mixture condition is converted to NH3 in the rich mixture condition and reduced in the following lean mixture condition. Thus, the new system allows the effective reduction of NOX. However, in order to realize cleaner emission gases, precise engine control in response to the state of the exhaust aftertreatment system is essential.
Technical Paper

Oxidation Stability of Automatic Transmission Fluids -A Study by the International Lubricants Standardization and Approval Committee (ILSAC) ATF Subcommittee

2001-05-07
2001-01-1991
The International Lubricant Standardization and Approval Committee (ILSAC) ATF subcommittee members have compared the two oxidation bench test methods, Aluminum Beaker Oxidation Test (ABOT) and Indiana Stirring Oxidation Stability Test (ISOT), using a number of factory-fill and service-fill ATFs obtained in Japan and in the US. In many cases, the ATFs were more severely oxidized after the ABOT procedure than after the same duration of the ISOT procedure. The relative severity of these two tests was influenced by the composition of the ATFs. The bench test oxidation data were compared with the transmission and the vehicle oxidation test data.
Technical Paper

Study on HCCI-SI Combustion Using Fuels Ethanol Containing

2007-10-29
2007-01-4051
Bio-ethanol is one of the candidates for automotive alternative fuels. For reduction of carbon dioxide emissions, it is important to investigate its optimum combustion procedure. This study has explored effect of ethanol fuels on HCCI-SI hybrid combustion using dual fuel injection (DFI). Steady and transient characteristics of the HCCI-SI hybrid combustion were evaluated using a single cylinder engine and a four-cylinder engine equipped with two port injectors and a direct injector. The experimental results indicated that DFI has the potential for optimizing ignition timing of HCCI combustion and for suppressing knock in SI combustion under fixed compression ratio. The HCCI-SI hybrid combustion using DFI achieved increasing efficiency compared to conventional SI combustion.
Technical Paper

Improvement of visibility for vulnerable parties in traffic accidents

2001-06-04
2001-06-0142
More than half of fatalities in traffic accidents in Japan are the vulnerable parties in such accidents (pedestrians, motorcycles, bicycles). In most of these accidents, the cause is collision involving automobiles. Therefore, reasoning that early detection of such vulnerable parties would lead to a reduction in accidents, we conducted research on the following three systems: - Honda Night Vision System - For night-time detection of pedestrians using infrared cameras. - Active Headlights - For assuring night-time field of vision by directing illumination in the direction of vehicle travel through lights coupled with steering wheel turn and so on. - Inter-Vehicle Motorcycle-Automobile Communication System (IVCS) - Notifies drivers of each other's presence by providing information through communications systems installed on both vehicles. The results from research on these systems show that their use can be expected to have a positive effect in reducing the occurrence of accidents.
Technical Paper

Development of a Magnetic Coupling Water Pump for a Four-Stroke 50cm3 Scooter Engine

2002-03-04
2002-01-0858
In the development of a magnetic-coupling water pump, the pulling-out (disengagement) of a coupling that led to the stopping of an impeller was a concern. Upon analysis of the behavior of the magnetic coupling, presence of two types of the pulling-out was found, that is, the pulling-out resulting from a lack of transfer torque in the high-speed revolutions and the pulling-out due to the resonance of an inner magnet and an outer magnet. Main factors that affect the pulling-out are the angular velocity input to the drive side, the moment of inertia of the driven side, characteristics of the magnetic coupling, and a damping from coolant. Using a measurement and simulation of the behavior of the water pump, factors were analyzed and the process of pulling-out was clarified. As a result, design specifications that prevented the pulling-out were established.
Technical Paper

32 Development of Silent Chain Drive System for Motorcycles

2002-10-29
2002-32-1801
Examining the noise reduction of a motorcycle, the requirement of an effective method of reducing a drive chain noise has been a pending issue similarly to noise originating from an engine or exhaust system, etc. Through this study, it became clear that the mechanism of chain noise could be classified into two; low frequency noise originated from cordal action according to the degree of chain engagement and high frequency noise generated by impact when a chain roller hits sprocket bottom. An improvement of urethane resin damper shape, mounted on a drive side sprocket, was effective for noise reduction of the former while our development of a chain drive that combined an additional urethane resin roller with an iron roller worked well for the latter. The new chain system that combined this new idea has been proven to be capable of reducing the chain noise to half compared with a conventional system.
Technical Paper

49 Development of Pb-free Free-Cutting Steel Enabling Omission of Normalizing for Crankshafts

2002-10-29
2002-32-1818
Crankshafts of motorcycles require high strength, high reliability and low manufacturing cost. Recently, a reduction of Pb content in the free-cutting steel, which is harmful substance, is required. In order to satisfy such requirements, we started the development of Pb-free free-cutting steel which simultaneously enabled the omission of the normalizing process. For the omission of normalizing process, we adjusted the content of Carbon, Manganese and Nitrogen of the steel. This developed steel can obtain adequate hardness and fine microstructure by air-cooling after forging. Pb-free free-cutting steel was developed based on Calcium-sulfur free-cutting steel. Pb free-cutting steel is excellent in cutting chips frangibility in lathe process. We thought that it was necessary that cutting chips frangibility of developed steel was equal to Pb free-cutting steel. It was found that cutting chips frangibility depend on a non-metallic inclusion's composition, shape and dispersion.
Technical Paper

47 Development of a Titanium Material by Utilizing Off-Grade Titanium Sponge

2002-10-29
2002-32-1816
Titanium alloy for forging and pure titanium material for exhaust systems have been developed. The forging alloy will be applied to production of lightweight motorcycle frames and the pure titanium will be applied to improve engine performance. The materials have been made inexpensive by the use of off-grade sponge that includes many impurities for production of titanium ingot. Stable characteristics have been obtained by controlling oxygen equivalent after setting the volume of tolerable impurities by considering mechanical properties and production engineering. In spite of low-cost, the material provides the same design strength compared to conventional material, and enables parts production with existing equipment. A review of manufacturing and surface treatment processes indicated a reduction in the price of titanium parts produced with this new material.
Technical Paper

Constitutive Modeling of Polymers Subjected to High Strain Rates

2001-03-05
2001-01-0472
A biaxial test procedure is used to assess the constitutive properties of polymers in tension. The constitutive constants are derived for high strain rate applications such as those associated with crashworthiness studies. The test procedure is used in conjunction with a time- and strain-dependent quasi-linear viscoelastic constitutive law consisting of a Mooney-Rivlin formulation combined with Maxwell elements. The procedure is demonstrated by describing the stress vs. strain relationship of a rubber specimen subjected to a step-relaxation input. The constitutive equation is transformed from a nonlinear convolution integral to a set of first order differential equations. These equations, with the appropriate boundary conditions, are solved numerically to obtain transient stresses in two principal directions. Material constants for use in the explicit LS-Dyna non-linear finite element code are provided.
Technical Paper

Development of the Motor-Assist System for the Hybrid Automobile--The Insight Development of the Motor-Assist System for a Hybrid Car--Insight

2000-11-01
2000-01-C079
A motor-assist system has been developed and employed for the "Insight' hybrid car. The system consists of an internal combustion engine as the primary power source, with an electric motor placed around the engine's crankshaft. Such construction reduces the system's volume significantly and offers more flexibility for the power plant layout. The system's functions include regeneration during braking, an idle stop mechanism, driving power assistance, and power supply for the 12V electrical system. A proper energy management method for various driving modes has been established by combining these functions, and fuel economy is significantly improved as a result. As another control feature, an active motor vibration control system compensates the idling vibration that is unique to three-cylinder engines.
Technical Paper

Basic Understanding of Activated Radical Combustion and Its Two-Stroke Engine Application and Benefits

2000-06-19
2000-01-1836
For a better understanding of the auto-ignition phenomenon in internal combustion engines, consideration is given from the in-cylinder gas temperature aspect. Experimental results demonstrate that the in-cylinder gas temperature at the end of compression, namely, the “auto-ignition temperature” is deeply involved in the onset of auto-ignition. The relation between the gas exchange state and the auto-ignition temperature explains the mechanism of timing controlled auto-ignition, namely, Activated Radical (AR) Combustion. The auto-ignition temperature is maintained constant during the AR combustion state, thanks to the exhaust valve controlling the hot residual gas amount. Finally, the utilization of auto-ignition in gasoline engines is discussed from the methodology aspect.
Technical Paper

Intake and Exhaust Systems Equipped with a Variable Valve Control Device for Enhancing of Engine Power

2001-03-05
2001-01-0247
The variable intake and exhaust control valve system for the in-line four-cylinder motorcycle engine was developed for realization of high engine power in all the engine speed ranges. Both the variable intake and exhaust control valves are operated by one servomotor. For high engine speeds, the exhaust collector pipe design for merging of each exhaust gas flow at 180 degrees phase difference is used. For mid engine speeds, the design for merging of each exhaust gas flow at 360 degrees phase difference is used. Two modes are provided to the intake control, and three modes are provided to the exhaust control. Along with exhaust-gas treatment systems such as the catalyst and air-injection system, high engine performance with optimum driveability and reduced emission are realized.
Technical Paper

On-board Diagnostic Expert System via an Enhanced Fault Tree Model

2006-04-03
2006-01-1567
We propose to enhance reliability based diagnosis by enhancing the fault tree model with a sensor layer for capturing evidence. We recognized the need for an automated diagnostic process that can predict and report component failure in vehicles prior to total failure of any system in the vehicle. We also want to take advantage of evidence that can be derived from sensors to reduce the amount of tests required to identify failed components.
Technical Paper

Ignition and Combustion Simulation in HCCI Engines

2006-04-03
2006-01-1522
Combustion simulation is an effective tool in overcoming the issues associated with gasoline HCCI engines, controlling ignition timing and extending the operating range. The research discussed in this paper commenced by optimizing the reaction mechanism from the perspective of ignition delay using the genetic algorithm (GA) method. Simulations employing the optimized reaction mechanism were then able to more accurately reproduce the ignition timing of iso-octane and primary reference fuels (PRF). Ignition times obtained from simulations showed excellent correlation with ignition times measured using these fuels in shock tube experiments, and in engines with both homogeneous and non-homogeneous fuel distributions. The use of the PRF mechanism for gasoline with an equivalent octane number enables excellent reproduction of ignition timing even when EGR is employed.
Technical Paper

Research and Analysis of ISG Belt-drive System for Idling Stop System

2006-04-03
2006-01-1501
To enable a belt-driven Integrated Starter Generator (ISG) to be used in an idle-stop system, the belt system must be capable of both driving the accessories and of starting the engine. Conventional belt systems required a higher tension setting to accomplish this, and the associated increase in friction opposed the achievement of better fuel economy. In this research, an auto-tensioner with a contraction suppression function that utilizes the incompressibility of fluid as well as a belt system that enables the auto-tensioner to be optimally located were proposed. The behavior of the belt system was measured in detail by testing, and the cause of the fluctuation of the belt tension was clarified by analysis. A method of controlling the ISG torque to flatten out tension fluctuations was devised, and its effectiveness was confirmed by simulation and testing. From the overall results of the research, a belt system that does not require a high tension setting was realized.
Technical Paper

Development of Hybrid System for 2006 Compact Sedan

2006-04-03
2006-01-1503
An Integrated Motor Assist (IMA) system for the 2006 Civic Hybrid has been developed, with the goal of having class leading fuel economy among compact vehicles and enhanced driving performance. The IMA system has been enhanced for greater power and efficiency. Combining the 3-stage i-VTEC engine with a higher power, higher efficiency electric motor assist mechanism enables an increase in deceleration regeneration energy and a drive mode powered by the electric motor alone. The engine is a newly developed 3-stage i-VTEC, based on the 1.3L SOHC i-DSI engine. The new 3-stage i-VTEC engine incorporates both a VTEC mechanism that switches cam profiles in low and high engine speed ranges, and a cylinder deactivation mechanism. The CVT has both an expanded ratio range and a higher final gear ratio. Through these technological enhancements, we have achieved the highest levels of fuel economy in the compact class and enhanced acceleration performance.
